Full color LED pharmacy cross 3D animation outdoor duble faces led cross display
Features:
● waterproof, radiation proof
● light weight, thin depth, front maintenance
● low power consumption, high bright, easy installation
● asynchronous control (RF/LAN/WIFI/RS232)
● display content 2D/3D(animation, graphic, text, time, temperature)
Specs:
|
Part Number |
Value |
|
Pixel Pitch |
20mm |
|
Physical Density |
61440dots |
|
Pixel configuration |
Three leds (RGB) |
|
LED lamp |
DIP504/546/546 |
|
Module Resolution |
16×8pixels |
|
Module Dimension |
320×160mm |
|
Cabinet Resolution |
64×64pixels |
|
Cabinet Dimension |
1690×1500×100mm |
|
Cabinet Weight |
78kg |
|
Brightness Level |
6000nits |
|
Max Power Consumption |
720W |
|
Ave Power Consumption |
240W |
|
Viewing Angle |
120°/60° |
|
Operating Power Source |
AC90-240V 50-60Hz |
|
Operating Temperature |
−20℃~+60℃ |
|
Drive Mode |
1/4 scan constant current |
|
Communication Mode |
RS232,RJ45,RF Wireless, WIFI--Default configuration(RF Wireless) |
|
Side |
One/two |
|
Life Span |
100,000Hours |
|
MTBF |
5,000Hours |
|
Protecting Rating |
IP65 |
|
Display Content |
animation, graphics, text, date, time, temperature, humidity |
|
Languages |
English, French, Spanish, Greek, Russian and Italian |
|
Operating system |
Windows (2000/XP/Vista/Win7) / Android / ios |
|
Verification |
CE, EMC, LVD, ROHS |
high bright LED pharmacy cross waterproof led cross screen for chemist's shop
LED pharmacy cross is one kind of heteromorphic display consisting of LED cross modules and cross cabinet. The system combines with the technology of optics, microelectronics, information processing and transmission, mechanics and other technology etc. as a whole. The main application areas: the chemist's shop, pharmacy, drugstore, Apotheke, farmacia, church, hospital and crossroad.
1) For outdoor usage, pour epoxy resin on the surface, full waterproof
2) Good quality with two side display, remote control board change the display shape.
3) Animations: all leds on, flashing, wave chasing
4) High bright LED for 100,000h
5) Input voltage: AC90-240V 50-60Hz,DC 5V
6) Power consumption: 240W
7) Other colors, sizes and one side available!
P20 pharmacy led display signs
Full Colour LED Pharmacy Cross can display time, date and temperature in different formats. Our displays can be programmed for automatic changes of displayed content – ie. one animation for an open pharmacy and different for a closed. For creating animations on the display you can use graphical or text effects such including; static, flashing, traveling, typewriter, diagonally, enter and exits, folding and unfolding, shutter, inverting colours, zoom, turn around, explosion, implosion and others ...
Displays automatically adjust their brightness or in hourly mode, they will dim at the set evening hours. The software also allows to automatically switch off the appliance at night.
